DSNM Solar Vaj Huam Sib Luag Txuas Txuas 440W-450W
High Efficiency Dual - Ik Iav Bifacial N Hom Solar Module
DSNM 440 ~ 450 series - High- Kev Siv Hluav Taws Xob Ua Si rau Cov Ntaub Ntawv Tshaj Tawm thiab Chaw Tso Khoom
Engineered rau kev xa khoom lag luam, DSNM 440 ~ 450 modules muaj ib qho kev sib tw dub rau cov niaj hnub, elegant zoo nkauj rau daim ntawv thiab muaj nuj nqi. Cov modules no xa cov kev ua kom muaj zog nrog sab saum toj -}}} kev xaiv zoo rau high-}} kev ua yeeb yam hnub ci.
Advanced Cell Technology rau cov tsim tawm zoo dua
Incorporating txiav - ntug rov qab thiab microcrystalline silicon (}} scicon (} modle module zog, ua kom muaj zog ntau dua rau lub sijhawm ntev.
Txog li 95% bifaciality rau siab dua lub zog tawm los
Tsim nrog cov qauv sib xws, cov qauv no ntes tau tshav ntuj ntxiv los ntawm sab nraub qaum, cuam tshuam ntau lub zog tso zis zog.
Cov huab cua thiab huab cua - tiv taus nrog pib sealing
Kev sib xyaw nrog cov pib - Cov qauv sib dhos, cov qauv sib ntsib I6}}}}} kav ntev txawm nyob hauv ib puag ncig hnyav.
Optimized rau nqi hluav taws xob - Cov phiaj xwm nplai
Nrog qis sib npaug ntawm cov txheej txheem (Bos) cov nqi thiab txo tus nqi hluav taws xob (ntsws), DSNM 440 ~ 450 - term kev cia siab.
Daim ntawv muaj cai
IEC 61215, IEC 61730, UL 61730 ISO9001: 2015: Iso Tswjhwm Zoo
ISO14001: 2015: ISO Kev Tswj Xyuas Ib Cheeb Tsam
ISO45001: 2018: Kev Noj Haujlwm Kev Noj Haujlwm thiab Kev Nyab Xeeb
IEC62941: Cov Lus Qhia rau Module Tsim Kev Tsim Nyog thiab Hom Pom Zoo
Kev Muaj Peev Xwm Zoo
Neeg kho tshuab tsis
|
Cell (Mm) |
182 * 91 mono |
| Qhov loj me (L * M * H) (hli) |
1722*1134*30 |
| Hnyav (kg) |
20.8 |
| CABLE Hla Hla (M㎡) | 4 |
| Tsis muaj ntawm cov hlwb & kev sib txuas |
108 (6*18) |
| Tsis muaj ntawm diodes | 3 |
Tsim nyog
| Max. Qhov System (V DC) | DC1500V (iEC) |
| Kub cycling ntau (degree) | -40~+85 |
| Max. Kev ntsuas hluav taws xob folding (a) | 25 |
| Kam rau pmax | 0~+3% |
| Max. Cua Load / Max. Daus Load (PA) | 2400 / 5400 |
| Kub Ceev Tus Nqi | 100% pub dawb |
|
Nominal ua hauj lwm cell kub (degree) |
45±2 |
| Kev Ntsuas Hluav Taws | Chav kawm c |
| BOUNTION BOX & PLAG TSIM NYOG TRUCK | Ms68 |
Cov Hluav Taws Xob Hluav Taws Xob
| DSNM 440 | DSNM445 | DSNM450 | ||
|---|---|---|---|---|
|
Stc AM1.5, 1000W / ㎡ Cell Kub 25 Qib |
Max. Fais fab ntawm STC (PMPP / W) | 440 | 445 | 450 |
| Max. Fais fab volfage (VMP / V) | 33.56 | 33.76 | 33.96 | |
| Max. Lub Hwj Chim Tam Sim No (Im) | 13.12 | 13.19 | 13.27 | |
| Qhib Circuit Courtage (VOC / V) | 39.83 | 40.03 | 40.23 | |
| Circuit Court Tam Sim No (ISC / A) | 14.15 | 14.23 | 14.31 | |
| Cov qauv hloov kho (%) | 22.5 |
22.8 |
23.0 | |
|
Noct AM1.5, 800W / ㎡, Ambient Kub 20 degree, Cua ceev 1M / S |
Max. Lub Hwj Chim ntawm Noct (PMPP / W) | 329 | 333 | 337 |
| Max. Fais fab volfage (VMP / V) | 30.62 | 30.81 | 30.99 | |
| Max. Lub Hwj Chim Tam Sim No (Im) | 10.75 | 10.82 | 10.88 | |
| Qhib Circuit Courtage (VOC / V) | 37.40 | 37.58 | 37.77 | |
| Circuit Court Tam Sim No (ISC / A) | 11.43 | 11.49 | 11.55 | |
Cov Khoom Siv Packing
| Thawv (Lub voos xwmfab) | |
|---|---|
| Modules ib pallet | 36 |
| Pallets ib lub thawv | 9 |
| Modules ib lub thawv | 943 |
Kub coefficients
| Kub coeigage (VOC) | -0.230% / Qib |
| Kub coefficient tam sim no (ISC) | 0.040% / Qib |
| Kub coefficient fais fab (PM) | -0.290% / Qib |
