Introduction Khoom taw qhia: | |
Ntawm tes | Mono 156.75mm HJT bifacial |
Tsis muaj ntawm cov | 60（6×10） |
Rated Tshaj Loj Fais Fab (Pmax) | 320W |
Hlaus Box | IP68 |
Qhov Siab Tshaj Plaws Cov Hluav Taws Xob | 1000V / 1500V DC (IEC) |
Kev khiav hauj lwm kub | -40℃～+85℃ |
Qhov ntev | 1658mm × 992mm × 5mm |
Nyhav | 20kg ± 3% |
Description Cov khoom qhia:
Heterojunction Technology (HJT) ua ke ua haujlwm siab nrog kev tsim qauv yooj yim txo cov naj npawb ntawm cov khoom ua tiav thiab ua tiav qhov txo tus nqi tseem ceeb. Nws ua ke qhov zoo ntawm mono crystalline silicon solar cells nrog kev nqus tau zoo thiab cov ua kom zoo dua cov yam ntxwv ntawm amorphous silicon ua rau muaj kev ua tau zoo dua.
Lub koob ntim thiab lub teeb ci dual-iav module nrog 2.0mm tempered iav tau zoo tsim nyob rau xyoo 2014. Tam sim no, thinner, sib zog dua-iav ob chav iav nrog 1.6 hli tempered iav encapsulated nrog siab efficiency HJT hnub ci cell tuaj yeem tsim. Vim tias cov khoom siv thiab tus yam ntxwv ua haujlwm, ob chav iav iav ua lub hauv paus kom tsis txhob muaj qhov tsis xws li PID, micro tawg ntawm cov hlwb, thiab qwj qwj, uas tuaj yeem txo cov peev txheej, thauj tus nqi thiab kev ua haujlwm ntawm cov fais fab nroj tsuag, thiab lwm yam
1 TSEEM CEEB
2 NEEG TXHEEJ TXHEEM DAG
3 KEV TSWJ RAUG RAU NPE ntawm STC
Rated Lub Zog Loj (Pmax) [W] | 305 | 310 | 315 | 320 |
Qhib Circuit Court Voltage (Voc) [V] | 39.85 | 40.15 | 40.46 | 40.86 |
Lub zog hluav taws xob tshaj plaws (Vmp) [V] | 33.23 | 33.59 | 33.92 | 34.25 |
Luv Circuit Court Tam Sim No (Isc) [A] | 9.73 | 9.77 | 9.84 | 9.89 |
Qhov ntau zog tam sim no (Imp) [A] | 9.18 | 9.23 | 9.29 | 9.35 |
Module efficiency [%] | 18.5 | 18.8 | 19.2 | 19.5 |
Lub hwj chim kam rau ua | 0~+5W | |||
Kub Coefficient ntawm Isc (α_Isc) | 0.048%/℃ | |||
Qhov kub thiab txias Coefficient ntawm Voc (β_Voc) | -0.271%/℃ | |||
Qhov kub thiab txias Coefficient ntawm Pmax (γ_Pmp) | -0.336%/℃ | |||
STC | Irradiance 1000W / m², cell kub 25 ℃, AM1.5G | |||
Hnub ci vaj huam sib luag yog ib qho khoom siv uas ncaj qha lossis tsis ncaj qha los hloov Hnub ci hluav taws xob lub zog rau hauv hluav taws xob los ntawm kev siv hluav taws xob photoelectric lossis photochemical effect los ntawm kev nqus lub hnub ci. Cov khoom siv tseem ceeb ntawm cov Hnub ci feem ntau yog" silicon", tab sis vim yog cov nqi ntau lawm, nws siv dav dav muaj qee yam kev txwv.
