Introduction Khoom taw qhia: | |
Ntawm tes | Tooj liab Indium Gallium Diselenide CIGS lub hnub ci cell |
Hloov chaw ntawm lub hnub ci cell | Polymer lossis iav lossis hlau ntawv ci |
Rated Tshaj Loj Fais Fab (Pmax) | 140W |
Hlaus Box | IP68 |
Qhov Siab Tshaj Plaws Cov Hluav Taws Xob | 1000VDC (IEC) |
Kev khiav hauj lwm kub | -40℃ ～ +85℃ |
Qhov ntev | 2583mm × 348mm × 17mm |
Nyhav | 2.1kg |
Description Cov khoom qhia:
Thin-film PV, tshwj xeeb hauv CIGS, yog lub thev naus laus zis tseem ceeb los ua ib qho ntawm cov thev naus laus zis yav tom ntej ntawm photovoltaics thiab muaj lub peev xwm loj rau cov thev naus laus zis txuas ntxiv. CIGS thin-zaj duab xis cov qauv tau nyiam ntau dua thiab ntau dua hauv kev lag luam hnub ci.
CIGS hnub ci module tuaj yeem siv dav ntawm sab hnub ci fais fab cog cog, daim phiaj hluav taws xob hnub ci hluav taws xob cog, portable hluav taws xob thiab lwm yam kev siv customized.
CIGS lub hnub ci hluav taws xob rau ntawm txheej sib txawv tuaj yeem tshaj tawm raws li:
Piv Txwv Lub Zog Zoo Li Cas-Rau-Qhov hnyav (50 - 250 watt / kg)
Ntau daim ntawv thov siv piv rau nruj raws li PV
Tso cai rau kom yooj yim Roll-to-Roll fabrication
Kev siv tau zoo dua ntawm cov khoom siv thiab kev tsim cov khoom hauv pem teb
Yas substrate tsis tawg lossis tawg raws li qhov cuam tshuam
Customizable (nrog Monolithic Kev Sib Txuas)
Yooj yim siv hluav taws xob thiab kev siv tshuab
Customized cell daim yooj yim sib xyaw rau hauv cov txheej txheem tsim khoom
Cov Ntsiab Lus Tseem Ceeb Tsim Tawm Hauv Thaj Chaw Me
Cov hluav taws xob ntau dua hauv kev lag luam ua tiav hauv thaj chaw me
CIGS lub hnub ci txuas tau li ntawm 90 txog 300 Watts DC, thiab tuaj yeem ua rau koj lub PV installation sai dua, yooj yim dua thiab tsis raug nqi rau koj kev lag luam thiab kev siv.
1 TSEEM CEEB
● Kev hais zoo nkauj ● Ua haujlwm siab txog 18,5% Flexible thiab khoov tau Weight Lub teeb hnyav thiab portable ● Dej tsis qab qis ● Kho tau yooj yim ntawm ntau yam surfaes Txhim khu kev qha thiab ruaj khov |
|
2 NEEG TXHEEJ TXHEEM DAG
3 KEV TSWJ RAUG RAU NPE ntawm STC
Rated Lub Zog Loj (Pmax) [W] | 110 | 115 | 120 | 125 | 130 | 135 | 140 |
Qhib Circuit Court Voltage (Voc) [V] | 36.33 | 37.2 | 37.81 | 38.65 | 39.44 | 40.13 | 40.92 |
Lub zog hluav taws xob tshaj plaws (Vmp) [V] | 28.41 | 29.32 | 30.34 | 31.26 | 32.12 | 33.06 | 33.92 |
Luv Circuit Court Tam Sim No (Isc) [A] | 4.67 | 4.62 | 4.59 | 4.54 | 4.51 | 4.46 | 4.52 |
Lub zog loj tshaj tam sim no (Imp) [A] | 3.91 | 3.93 | 3.98 | 4.03 | 4.07 | 4.13 | 4.15 |
Module efficiency [%] | 14.40% | 15.00% | 15.70% | 16.40% | 17.00% | 17.70% | 18.30% |
Lub hwj chim kam rau ua | 0~+5W | ||||||
Kub Coefficient ntawm Isc (α_Isc) | 0.008%/℃ | ||||||
Qhov kub thiab txias Coefficient ntawm Voc (β_Voc) | -0.281%/℃ | ||||||
Kub Coefficient ntawm Pmax (γ_Pmp) | -0.379%/℃ | ||||||
STC | Irradiance 1000W / m², cell kub 25 ℃, AM1.5G | ||||||
