Khoom piav qhia

Lub hnub ci dej twj tso kua mis muaj lub hnub ci vaj huam sib luag, PV dej twj tso kua mis tswj qhov system thiab twj tso kua mis.

1. Hnub ci vaj huam sib luag system: Hnub ci vaj huam sib luag yog nyob rau hauv series thiab kev sib txuas ua ke; Hloov lub hnub ci irradiance rau hauv hluav taws xob los muab lub zog rau lub twj tso kua mis.
2. Photovoltaic dej twj tso kua mis tswj qhov system: Nws tswj tag nrho cov twj tso kua mis, tig instable DC voltage ntawm lub hnub ci vaj huam sib luag system rau hauv DC voltage ruaj khov.rau lub twj tso kua mis, thiab tswj cov zis tam sim no raws li lub hnub ci siv kom ua tiav qhov siab tshaj plaws lub zog taw tes nrhiav (MPPT), ua kom siv lub hnub ci zog.
3. Lub hnub ci twj tso kua mis: Nws muaj lub cev twj tso kua mis, lub cev muaj zog, cov kav dej, cable, kev tiv thaiv cov cuab yeej, cov dej ntsuas ntsuas.

Daim ntawv thov

Lub hnub ci twj tso kua mis tuaj yeem ua haujlwm nyob rau nruab hnub, thaum lub hnub ci qis dua. Yog li ntawd nws yog tsim rau irrigation, vaj, chaw, tsev neeg, pastoral grassland, roob, tshwj xeeb tshaj yog ua hauj lwm nyob rau hauv cov cheeb tsam uas tsis muaj hluav taws xob.

Khoom feature

1. Dej twj tso kua mis tswj qhov system muaj cov khoom siv tiv thaiv hluav taws xob ua tiav, tiv thaiv hauv qab -voltage, tshaj -voltage, tshaj - ntws, overload, waterless, thiab lwm yam;
Tsis tas li ntawd nrog lub tshuab hluav taws xob tsis siv neeg thiab qib dej sensor uas tuaj yeem qhib / tawm lub twj tso kua mis thaum lub qhov dej qhuav thiab lub tank dej puv.

2. Lub taub hau twj tso kua mis: 19-190m, Flow rate: 1.6-31M3 / h.

3. Ua haujlwm kub: -20-50 ° C

Kev pab lub neej:

Hnub ci vaj huam sib luag: 20-25 xyoo;
Pump cotroller: 10 xyoo
Dej twj tso kua mis: 30,000hours.

Daim ntawv teev npe

320W Hnub Ci Vaj Huam Sib Luag Powered 240W DC Dej Twj
Qhov system Cov ntaub ntawv yooj yim	Solar DC twj tso kua mis: 120w+120w Lub sijhawm ua haujlwm ntawm lub cev: lub sijhawm hnub ci		QTY
Hnub ci vaj huam sib luag	Hom: mono hnub ci vaj huam sib luag (poly yeem) Max zog: 160w Lub hwj chim: 18.4V; 23V pom 8,75a; ib 9.35a Pem hauv ntej iav: 3.2mm Tempered Terminal thaiv: IP65 nrog MC4 connector Kev ua tau zoo: 25 xyoo 80%, 20 xyoo 85%, 10 xyoo 90% 2 pcs hauv series		2 Pcs
Solar DC twj tso kua mis	1) Qauv: 10L-120W Pump muaj peev xwm: 120W / 24VDC Dej ntws: 10L / min Lifting nrug: 80M Txoj kab uas hla: 450 * 76mm Kev sib hloov ceev: 18000rpm Kev tiv thaiv chav kawm: IP68 Cov khoom siv twj tso kua mis: lub taub hau yas	2) Qauv: 45L-120W Pump muaj peev xwm: 120W / 24VDC Dej ntws: 50L / min Lifting nrug: 10M Txoj kab uas hla: 530 * 76mm Kev sib hloov ceev: 18000rpm Kev tiv thaiv chav kawm: IP68 Cov khoom siv twj tso kua mis: tooj dag taub hau	2 Unit
Pump controller	Rated zog: 150w, 12V / 24V MPPT maub los: 0-200V MPPT kev ua tau zoo: 99.5% Kev Tiv Thaiv: Txhim khu thunderstorm & surge tiv thaiv		2 Unit
Solar vaj huam sib luag hauv av khib	Pem teb khib installation Cua load: 55m / s; Snow load: 1.5kN/m2 Qauv: Anodized Aluminium + stainless hlau, Lub kaum sab xis adjustable (lwm hom khib tuaj yeem kho raws li tus neeg siv khoom xav tau)		1 Unit
Cables	Los ntawm lub hnub ci vaj huam sib luag rau inverter: 4mm2 PV cable: 50M Los ntawm inverter mus rau lub twj tso kua mis: 3 * 2.5mm2 AC cable: 50M		1 Unit
Lub sijhawm ua haujlwm: Lub sijhawm tshav ntuj

Cov yam ntxwv tseem ceeb

Ua tau zoo heev hnub ci vaj huam sib luag

Submersible twj tso kua mis

Pib- nrawm nrawm, ua haujlwm tau zoo thiab muaj zog ruaj khov

Tshem tau ua ntej -filter

Multi spray qauv adapters

Kev ceev faj rau kev siv

Thov tsis txhob ua kom lub twj tso kua mis ua haujlwm yam tsis muaj dej rau lub sijhawm ntev, nws yuav ua rau lub twj tso kua mis lub neej luv luv.

Raws li lub zog ntawm lub hnub ci vaj huam sib luag yog nyob ntawm lub hnub ci, lub twj tso kua mis kuj cuam tshuam rau huab cua, caij nyoog, qhov chaw, thiab lwm yam.
