32 Hlwb Txawb Thiab Txawb 110W Monocrystalline Hnub Ci Vaj Huam Sib Luag

32 Cells Flexible And Portable 110W Mono Solar Panel

32 cells flexible and portable 110W monocrystalline solar panel

32 Hlwb Txawb Thiab Txawb 110W Monocrystalline Hnub Ci Vaj Huam Sib Luag

Khoom Taw qhia:

Tsev neeg lub hnub ci vaj huam sib luag hloov tau tsim nrog 8x4 hlwb array, thiab nrog kev ntsuas siab tshaj plaws hwj chim Pmax los ntawm 95W txog 110W, thiab nrog ntau zog hluav taws xob los ntawm 16V txog 18V DC. ● Dav siv rau RV, Golf tsheb, Tsheb fais, nkoj nkoj, tub rog, lub tsev pheebsuab lossis lub hnab ev ntawv ect. ● Tshaj tawm nrog kev sib txuam sib kis rov qab lub hnub ci sib luag (kev ua haujlwm txog 22% -24%), Module efficiency 30% siab dua ntawm cov hnub ci vaj huam sib luag. kev teeb tsa thiab vaj huam sib luag khoov mus txog 30 degrees. ● Lub thawv ntim dej tsis sib xws (ntxig diode) ● Cov xim dawb thiab xim dub muaj. ● Cov khoom pov tseg nyob rau hauv kaum nrog Stainless grommets, kev txhim kho yooj yim. ● 3mm tuab thiab lub teeb yuag rau siv.

Xa kev nug

Tsham tam sim no

Hauj lwm lawm

Kev tsis

Introduction Khoom taw qhia:
Ntawm tes	Mono 125mmx125mm
Tsis muaj ntawm cov	32（8×4）
Rated Tshaj Loj Fais Fab (Pmax)	110W
Hlaus Box	IP65
Cov yam ntxwv raug	semi yooj ywm thiab portable
Kev khiav hauj lwm kub	-40℃～+85℃
Qhov ntev	1050mm x 540mm x 3 hli
Nyhav	2kg

Description Cov khoom qhia:

Panel Tsev neeg no ua lub hnub ci vaj huam sib luag tau tsim nrog 8x4 hlwb ntxig, thiab nrog kev ntsuas siab tshaj plaws hwj chim Pmax los ntawm 95W txog 110W, thiab nrog ntau zog hluav taws xob los ntawm 16V txog 18V DC.

● Dav siv rau RV, Golf tsheb, Tsheb fais fab, nkoj tsav nkoj, tubrog nkoj, tsev pheebsuab lossis hnab ev ntawv ect.

● Kev ua haujlwm nrog kev sib tsuam rov qab sib cuag lub hnub ci lub hnub ci (kev ua kom zoo li 22% -24%), Cov txiaj ntsig efficiency 30% siab dua cov hnub ci vaj huam sib luag.

Nrog cov ntaub ntawv zoo siab tshaj plaws, cov khoom sib xyaw kom sib zog, tso cai rau kev thauj mus los yooj yim, teeb tsa thiab vaj huam sib luag khoov mus txog 30 degrees.

Box Lub thawv ntim dej tsis sib xws (ntxig diode).

● Dawb thiab Dub xim muaj.

Cov khoom ntsiag to hauv lub ces kaum nrog Stainless grommets, txhim kho yooj yim.

Mm 3mm tuab thiab lub teeb yuag rau kev siv portable.

1 TSEEM CEEB

Features of 32 cells flexible and portable 110W monocrystalline solar panel

2 NEEG TXHEEJ TXHEEM DAG

32 cells flexible and portable 110W monocrystalline solar panel.jpg

3 KEV TSWJ RAUG RAU NPE ntawm STC

Rated Lub Zog Loj (Pmax) [W]	95	100	105	110
Qhib Circuit Court Voltage (Voc) [V]	20.67	21.41	22.12	22.83
Lub zog hluav taws xob tshaj plaws (Vmp) [V]	16.25	17.11	17.95	18.81
Luv Circuit Court Tam Sim No (Isc) [A]	6.28	6.29	6.30	6.31
Qhov ntau zog tam sim no (Imp) [A]	5.88	5.88	5.89	5.90
Module efficiency [%]	16.75%	17.64%	18.52%	19.40%
Lub hwj chim kam rau ua	0~+3%
Kub Coefficient ntawm Isc (α_Isc)	0.056%/℃
Qhov kub thiab txias Coefficient ntawm Voc (β_Voc)	-0.298%/℃
Qhov kub thiab txias Coefficient ntawm Pmax (γ_Pmp)	-0.359%/℃
STC	Irradiance 1000W / m², cell kub 25 ℃, AM1.5G
